    GPON Terminal , Fiber Modem , PK FiberHome AN5506-01A Huawei HG8010 HG8310M

    GPON Terminal , Fiber Modem , PK FiberHome AN5506-01A Huawei HG8010 HG8310M


    Key Specifications/Special Features:

    The GPON ONU HG8010H/HG8310M/F601 (PK FiberHome AN5506-01A) is an indoor optical network terminal (ONT) in FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users. The GPON ONU provides one GE/FE auto-adapting Ethernet port. The GPON ONU features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video


    ChassisRack1U 19-inch standard box
    Slots1*10 Gigabit uplink card slot
    2 power module slot
    Uplink portCopper8*10/100/1000M auto-negotiable
    SFP8 SFP slots (1000BASE-TX interface)
    10GE card2 SFP (optional)
    PON portQuantity8
    Physical InterfaceSFP slots
    Connector typeITU-TG.984.2Class B+
    Max splitting ratio1:128
    Management ports1 10BASE-TX out band port
    1 CONSOLE port
    PON port specification
    (Apply to OPTOSTAR PON module)
    Transmission distance: 20km, PON port speed: Downstream data rate: 2.5Gbps, upstream data rate: 1.25Gbps, wavelength: 1490nm TX,1310nm RX, Connector: SC,
    Fiber type: 9/125μm SMF, TX power: +1.5-+5dBm,
    Rx sensitivity: -28dBm, saturation optical power: -8dBm
    Management modeSNMP, Telnet, CLI
    Management functionssupports for state monitoring, configuration management, equipment log, equipment upgrades, equipment management, user management
    Layer-2 switch configuration such as Vlan, Trunk, RSTP, IGMP, QOS
    PON management function: DBA ,ONT authorization, ACL, QOS, online ONT configuration and management
    user management
    alarm management
    Dimension(L) 440 * (W) 391 * (H) 44mm
    Weight4kg
    Power supply220V ACAC: 90-240V, 47/63Hz
    -48DCDC: -36-72V
    Power consumption65W
    Operating environmentWorking temperature0 to 50°C
    Storage temperature-40 to 85°C
    Relative humidity5-90%(non condensing)
